C 569
CD PLAYER
- Regular Price
- $999.00
Sold Out
SPECIFICATIONS
| Specification | Details |
|---|---|
General Specifications |
|
| Output level |
Line Out: 2.2 ±0.2V Digital Audio Out - Coaxial: 0.5 – 0.8 Vp-p 75 ohms |
| Frequency response | 0 dB, 20 Hz - 20 kHz (±0.5 dB) |
| Total harmonic distortion | ≤0.006% (1kHz, LPF 20kHz) |
| Signal/Noise ratio | ≥110 dB (1 kHz, A-weighted LPF 20 kHz Play) |
| Channel balance | 0.5 dB (0 dB 1 kHz) |
| Channel separation | ≥110 dB |
| De-emphasis |
-3.73 to -5.33 dB (0 dB 1kHz, 5 kHz) -8.04 to -10.04 dB (0 dB 1 kHz, 16 kHz) |
| Linearity |
-3 ±0.1 dB (0 dB 1 kHz at -3 dB) -6 ±0.2 dB (0 dB 1 kHz at -6 dB) -10 ±0.25 dB (0 dB 1 kHz at -10 dB) -20 ±0.25 dB (0dB 1 kHz at -20 dB) -60 ±0.5 dB (0dB 1 kHz at -60 dB) |
| Standby power | <0.5W |
| Idle power | ≤ 20 W |
Weight & Dimensions |
|
| Gross dimensions (W x H x D) |
435 x 83 x 294 mm 17 1/4 x 3 3/8 x 11 5/8 inches |
| Net weight | 4.2 kg (9.2 lbs) |
| Shipping weight | 6.2 kg (13.7 lbs) |
Notes |
|
|
*Gross dimension includes feet and extended rear panel terminals Specifications are subject to change without notice. For updated documentation and features, please check out [www.NADelectronics.com](https://www.NADelectronics.com) for the latest information about C 569. |
|
